iFLYTEK Far-Field Microphone Array Module ROS Six-Microphone Voice Board 6-Microphone Sound Source Positioning Navigation
- Real-time Translation
- Sound Source Localization
- Support ROS
- TTS (Text to Speech)
- Offline Voice Recognition
- Echo Cancellation
- Audio Noise Reduction
Expansive 10-Meter Pick-Up Range
By harnessing iFLYTEK's far-field noise reduction technology, the microphone array achieves a pick-up range of 10 meters, surpassing the performance of the 1st generation ring microphone array.
360° Sound Source Localization
Utilizing microphone array technology, it achieves 360° speech signal collection. Through the TDOA algorithm (Time Difference of Arrival), it calculates the angle between the sound source and the module, accurately determining the speaker's direction. It can provide the azimuth angle and resolution of the sound source, up to 1°.
Offline Voice Recognition
Utilize the iFLYTEK offline voice recognition engine for offline voice recognition capabilities.
Support iFLYTEK Voice Cloud Service
The microphone array can be integrated with iFLYTEK voice cloud service for features like pronunciation correction and voiceprint recognition. (Registration is required.)
Support Text to Speech (TTS)
Echo Cancellation
Voice Wake Up
Noise-Reduced Audio
Provide Configured Development Environment
The module primarily supports Linux systems, with additional compatibility for Android. For customers lacking a Linux environment but requiring development of related technologies, we offer a pre-configured Linux virtual machine image specifically designed for Windows. This image can be easily downloaded and installed for immediate use.
Universal UAC Protocol
The audio output of the ring 6-microphone array is compatible with the universal UAC protocol, allowing for plug-and-play functionality. The computer system can access the audio without requiring any special driver adaptation.
Support Serial Port Communication
The wake-up status, along with the wake-up angle and other relevant information, can be retrieved through the serial port.
Support PC/ Raspberry Pi/ Jetson Nano
The microphone array includes development tutorials and ROS source code for PC, Raspberry Pi, and Jetson Nano platforms. It is compatible with a variety of controllers, meeting diverse development needs of users.
| Item | Specification |
| Product model | 6-microphone array |
| Microphone quantity | 6 |
| Sound source localization accuracy | 1° |
| Pick up range | 10m |
| Angle range | 360° |
| Multiple wake-up voice command | Support |
| Customized voice reduction | Support |
| Voice reduction | support |
| Echo canceling | Support |
| Offline recognition | Support |
| Voice command recognition limitation | unlimited quantity of voice commands. But each command cannot exceed 10 words |
| Work with robot | support. Realize voice control navigation and voice control movement |
| Linux development | Complete SDK routine is provided for offline voice command recognition, recognition result, wake-up angle and audio feedback |
| Windows/ Linux serial port control | Support |
| Windows/ Linux reads audio | Support |
| iFLYTEK voice cloud service | Support |
Shipping & Delivery
1. Free Shipping Policy
Hiwonder offers free standard shipping on orders over US $499 (before tax and duties), delivered via trusted carriers such as DHL, UPS, or FedEx.
Most orders arrive within 6 working days after dispatch. You can check if your country is eligible for free shipping in the regions listed below.
Eligible Regions
- Americas: United States, Canada, Mexico, Chile
- Europe: Germany, United Kingdom, Netherlands, Switzerland, France, Austria, Italy, Belgium, Spain, Sweden, Finland, Norway, Portugal, Czech Republic, Poland, Greece, Slovenia, Romania, Denmark, Bulgaria, Luxembourg, Slovakia, Hungary, Ireland, Estonia, Lithuania
- Asia: China, Japan, Singapore, South Korea, United Arab Emirates, Malaysia, Thailand, Philippines, Indonesia
- Oceania: Australia, New Zealand
If your country or region is not listed above, the shipping cost will be automatically calculated at checkout once you enter your shipping address.
2. Customs & Import Fees
All international shipments are subject to local customs regulations. Import duties, taxes, or other fees may be charged by your country's customs authority upon arrival.
Our shipping term is FOB Shenzhen, which means these fees, if any, are the customer's responsibility. The shipping carriers will assist with the customs clearance process to ensure smooth delivery.
If a package is returned due to unpaid customs duties, any related return or reshipping fees will be deducted from your refund.
3. Order Processing Time
Orders are typically processed within 24 hours after placement and shipped the next business day.
Orders placed on weekends or public holidays will be shipped on the next working day.
Once shipped, you will receive a confirmation email with tracking information.
Questions & Answers
Have a Question?
-
how can i navigate throw these materials, i am using ubuntu os
Hi there, this is the tutorial link for you: https://www.hiwonder.com.cn/store/learn/135.html
If you need more support, pls feel free to contact us! Email: support@hiwonder.com
-
i am customer, i need to source code get anger from source sound or control echo, noise, ... not independent ros2 ?
Hi there,
You can refer to Linux_SDK (File 2) and Android_SDK (File 6) for guidance. It’s not necessary to use ROS2.
Link: https://drive.google.com/drive/folders/151q14FjyEqSSgfXeqeRfvVZp2wXK2rJu?usp=sharing
Let me know if you have any questions.
-
does it support ROS2?
Yes, it supports ROS2
-
Where can i find the tutorials?
You can check this link: https://www.hiwonder.com.cn/store/learn/119.html
