Hiwonder LD-3015MG Full Metal Gear Digital Servo with 17kg High Torque for RC Robot Car
Product SKU: 21100002
- 17kg large torque. 15 kg·cm (208 oz·in) 6V
- 17 kg·cm (236 oz·in) 7.4V
- Full metal gear
- 270 degree rotation
- Using high-precision potentiometer with new design
- Dimension: 54.5mm*20mm*47.5mm (2.14inch*0.78inch*1.87 inch)
Available:
Only 985 items in stock
In stock
In stock
Out of stock
Back in stock
$13.99
Save
% $-13.99
Product Description
Hiwonder LD-3015MG is a full metal gear standard digital servo with 17 kg high torque, using aluminum case for Robotic RC Car with control angle 270 degrees.
Feature
- 17KG large torque. 15 kg·cm (208 oz·in) 6V; 17 kg·cm (236 oz·in) 7.4V
- Full metal gear. Improve servo’s accuracy and extend its service time
- 270 degrees rotation. Controllable angle range from 0 to 270 degrees, excellent linearity, precision control
- It can rotate within 360 degrees when power off
- Use high-precision potentiometer with a new design. Accuracy and linearity have been greatly improved
- Dimension: 40mm*20mm*40.5 mm（1.575 inch*0.787 inch* 1.594 inch）
Metal Gear
15kg Large Torque
270° Rotation Degree
Packing List
1* LD-3015MG digital servo
1* 30cm servo wire
1* servo horn kit
1* 30cm servo wire
1* servo horn kit
| Item | Specification |
| Weight | 62g(2.18OZ) |
| Dimension | 40mm*20mm*40.5 mm(1.575 inch*0.787 inch* 1.594 inch) |
| Speed | 0.16sec/60°(7.4V) |
| Accuracy | 0.4° |
| Torque | 15 kg·cm (208 oz·in) 6V;17 kg·cm (236 oz·in) 7.4V |
| Working Voltage | 6-7.4V |
| Min Working Current | 1A |
| No-load Current | 100mA |
| Spline | 25T (6mm diameter) |
| Servo Wire | 30cm (11.8inch) in length |
| Control Method | PWM |
| Pulse Width | 500~2500us, to (0~270deg) |
| Duty Ratio | 0.5ms~2.5ms |
| Pulse Period | 20ms |
| Wire Layout | red wire: + black wire: GND white wire: PWM/signal |
| Package List | 1* digital servo 1* 30cm servo wire 1* servo horn kit |
Please make sure that the duty cycle of the controller you used is confirmed to our specifications, otherwise, the servo can't turn up to a claimed degree.
Important Tips
-
Recommend to use lithium polymer battery with high rate discharge(min 5C), please don't use the dry battery.
-
Please use a short and thick power cord, don't use Dupont cord.
