Hiwonder LX-224 Serial Bus Servo with Three Connectors /20KG Large Torque
- Serial bus servo connector to connect the servo one by one
- High-precision potentiometer to feedback the angle position
- Equipped with position/temperature/voltage feedback
- Support two working mode: Servo mode and Gear motor mode
- 20KG large torque.Dual ball bearing
Product Description
LX-224 servo is a full metal gear serial bus servo with three connectors. The servo can be connected in series, simplifying the wire connection.It can provide temperature, position feedback. LX-224 servo can be used in different bionic robot joints.
Packing List
- 1*LX-224 servo
- 1*Plastic main servo horn
- 1*Plastic assistant servo horn
- 1*Servo wire(200mm)
- 1*Screw package
| Weight | 63g |
| Size | 40 x 20.14 x 51.1 mm |
| Working voltage | 6-8.4V |
| Speed | 0.20sec/60°7.4V |
| Torque | 20kg.cm 7.4V |
| Rotation | 0-240° |
| No-load current | 100mA |
| Stall Current | 2.4~3A |
| Servo accuracy | 0.3° |
| Control method | UART serial command |
| Communication baud rate | 115200 |
| Storage | Save data when the power off |
| Servo ID | 0~253 for user setting, ID 1 is default |
| Angel read back function | Support |
| Protection | Avoid stalling and overheat |
| Data feedback | Temperature, Voltage, Position |
| Working mode | Servo mode and deceleration motor mode |
| Control angle range | 0-1000, correspond to 0-240° |
| Wire | 200mm |
| Gear | Metal |
Bus Servo Communication
The user can set and assign an ID number to each servo, and use the controller to issue instructions to make the servo perform actions according to the instructions.
High Torque and Strong Power
The servo has a maximum torque of 20kg.cm 7.4V, which is powerful and gives your robot plenty of power.
High Quality Potentiometer
The servo adopts a high-precision potentiometer, which improves the accuracy and linearity, makes the operation more stable and prolongs the service life.
Intelligent Feedback and Two Working Modes
The servo supports servo mode and reduction motor mode, and has position, temperature and voltage feedback to protect the normal operation of the servo.
| Item | Specification |
| Weight | 63g |
| Size | 40*20.14*51.1mm |
| Working voltage | 6-8.4V |
| Speed | 0.20sec/60°7.4V |
| Torque | 20kg.cm 7.4V |
| Rotation | 0-240° |
| No-load current | 100mA |
| Stall Current | 2.4~3A |
| Servo accuracy | 0.3° |
| Control method | UART serial command |
| Communication baud rate | 115200 |
| Storage | Save data when the power off |
| Servo ID | 0~253 for user setting, ID 1 is default |
| Angel read back function | Support |
| Protection | Avoid stalling and overheat |
| Data feedback | Temperature, Voltage, Position |
| Working mode | Servo mode and deceleration motor mode |
| Control angle range | 0-1000, correspond to 0-240° |
| Wire | 200mm |
| Gear | Metal |
Shipping & Delivery
1. Free Shipping Policy
Hiwonder offers free standard shipping on orders over US $499 (before tax and duties), delivered via trusted carriers such as DHL, UPS, or FedEx.
Most orders arrive within 6 working days after dispatch. You can check if your country is eligible for free shipping in the regions listed below.
Eligible Regions
- Americas: United States, Canada, Mexico, Chile
- Europe: Germany, United Kingdom, Netherlands, Switzerland, France, Austria, Italy, Belgium, Spain, Sweden, Finland, Norway, Portugal, Czech Republic, Poland, Greece, Slovenia, Romania, Denmark, Bulgaria, Luxembourg, Slovakia, Hungary, Ireland, Estonia, Lithuania
- Asia: China, Japan, Singapore, South Korea, United Arab Emirates, Malaysia, Thailand, Philippines, Indonesia
- Oceania: Australia, New Zealand
If your country or region is not listed above, the shipping cost will be automatically calculated at checkout once you enter your shipping address.
2. Customs & Import Fees
All international shipments are subject to local customs regulations. Import duties, taxes, or other fees may be charged by your country's customs authority upon arrival.
Our shipping term is FOB Shenzhen, which means these fees, if any, are the customer's responsibility. The shipping carriers will assist with the customs clearance process to ensure smooth delivery.
If a package is returned due to unpaid customs duties, any related return or reshipping fees will be deducted from your refund.
3. Order Processing Time
Orders are typically processed within 24 hours after placement and shipped the next business day.
Orders placed on weekends or public holidays will be shipped on the next working day.
Once shipped, you will receive a confirmation email with tracking information.
Questions & Answers
Have a Question?
-
What is the voltage range for the Serial RX/TX data pin? Is there a data sheet available?
The voltage range is between 0V and 3.3V, or 0V and 5V, depending on the configuration
-
What is the screw size for the LX244 servo?
2*5 self-tapping screw
