MasterPi Hiwonder AI Vision Robot Arm with Mecanum Wheels Car Powered by Raspberry Pi Open Source Robot Car
Product SKU: HW2019204
- Powered by Raspberry Pi 4B/ CM4
- Tiny desktop robot car with 5DOF robot arm
- Learn AI machine vision by OpenCV
- Realize omni-directional movement with mecanum wheels car
- FPV vision for intelligent picking, target tracking, object sorting, etc
Available:
Only 984 items in stock
In stock
In stock
Out of stock
Back in stock
$199.99
Product Description
Powered by Raspberry Pi 4B and equipped with mecanum wheel chassis car, 5DOF robotic arm and HD camera, MasterPi is able to carry out color sorting, target tracking, line following, intelligent transport, etc by OpenCV.
Combining with RGB glowy ultrasonic sensor, it can control light colors and perform obstacle avoidance. In addition, various sensors can be installed on MasterPi for more perception functions. With abundant tutorials and open source Python codes, MasterPi is a perfect helper for you to learn robot technology and robot vision to be a real AI player!
Combining with RGB glowy ultrasonic sensor, it can control light colors and perform obstacle avoidance. In addition, various sensors can be installed on MasterPi for more perception functions. With abundant tutorials and open source Python codes, MasterPi is a perfect helper for you to learn robot technology and robot vision to be a real AI player!
Powered by Raspberry Pi 4B and equipped with mecanum wheel chassis car, 5DOF robotic arm and HD camera, MasterPi is able to carry out color sorting, target tracking, line following, intelligent transport, etc by OpenCV.
Combining with RGB glowy ultrasonic sensor, it can control light colors and perform obstacle avoidance. In addition, various sensors can be installed on MasterPi for more perception functions. With abundant tutorials and open source Python codes, MasterPi is a perfect helper for you to learn robot technology and robot vision to be a real AI player!
Combining with RGB glowy ultrasonic sensor, it can control light colors and perform obstacle avoidance. In addition, various sensors can be installed on MasterPi for more perception functions. With abundant tutorials and open source Python codes, MasterPi is a perfect helper for you to learn robot technology and robot vision to be a real AI player!
Smart Games Make Programming Learning More Fun
Smart Games Make Programming Learning More Fun
Color Recognition
Color Sorting
Target Tracking
Line Following
Obstacle Avoidance
Remote Control
Color Recognition
Color Sorting
Target Tracking
Line Following
Obstacle Avoidance
Omni-directional Movement, First Person View
Omni-directional Movement, First Person View
360° Omni-directional Movement
360° Omni-directional Movement
With omni-directional mecanum wheels, MasterPi can realize 360°movement. Different movement modes (move forward, horizontally, diagonally and rotate ) and excellent performance enable it challenge various complicated routes easily.
With omni-directional mecanum wheels, MasterPi can realize 360°movement. Different movement modes (move forward, horizontally, diagonally and rotate ) and excellent performance enable it challenge various complicated routes easily.
Object Transport, First Person View
Object Transport, First Person View
Loaded with a 5DOF robotic arm, MasterPi can pick and transport the target object with ease. Combined with HD camera ending in robot arm, it can provide first person view.
Loaded with a 5DOF robotic arm, MasterPi can pick and transport the target object with ease. Combined with HD camera ending in robot arm, it can provide first person view.
AI Vision Recognition, Target Tracking
MasterPi takes OpenCV as image processing library and utilizes FPV to recognize and locate the target block so as to realize color sorting, target tracking, line following, and other AI games.
Target Tracking
Through vision positioning of the target object and inverse kinematics algorithm of the robotic arm, the target object can be better targeted and tracked.
Color Sorting
With abundant tutorials and open source Python codes, robotic arm can carry out color recognition, picking and sorting.
Line Following
Through extracting ROI area with OpenCV, eliminating noise, image binaryzation and etc, to realize line following
AI Vision Recognition, Target Tracking
MasterPi takes OpenCV as image processing library and utilizes FPV to recognize and locate the target block so as to realize color sorting, target tracking, line following, and other AI games.
Color Sorting
With abundant tutorials and open source Python codes, robotic arm can carry out color recognition, picking and sorting.
Target Tracking
Through vision positioning of the target object and inverse kinematics algorithm of the robotic arm, the target object can be better targeted and tracked.
Line Following
Through extracting ROI area with OpenCV, eliminating noise, image binaryzation and etc, to realize line following.
First Person View, HD Transmitted Image
First Person View, HD Transmitted Image
MasterPi supports WLAN and WIFI direct connection modes. Connecting WiFi, the first person view will be returned to app operation interface, which gets remote control more exciting and real!
MasterPi supports WLAN and WIFI direct connection modes. Connecting WiFi, the first person view will be returned to app operation interface, which gets remote control more exciting and real!
Real-time Remote Control
Real-time Remote Control
Use App to control Masterpi to move, pick and transport at your fingertips
Use App to control Masterpi to move, pick and transport at your fingertips
Quick Experience AI Games
Quick Experience AI Games
Switch robot modes easily and quickly to experience AI games.
Switch robot modes easily and quickly to experience AI games.
Support Python
Support Python
6 Hardware Features
6 Hardware Features
15KG Strong Torque
15KG Strong Torque
The base of robotic arm uses full metal and 15KG strong torque servo equipped with metal servo horn for stronger power feedback.
Metal Gear Micro Servo
Metal Gear Micro Servo
The end of robotic arm uses metal gear micro servo equipped with metal servo horn for higher accuracy and longer service life！
Hard Aluminium Alloy
It protects the core control board from shattering and shocking and can bear bigger load!
120° HD Camera
Loaded with 120 °camera, visual angle and tilt angle can reach 180°. Combined with mecanum chassis car, the vision range is 360°.
Glowy Ultrasonic Sensor
Lower CPU consumption for better performance. Distance to obstacles and light colors are adjustable in App.
Hard Aluminium Alloy
120° HD Camera
Glowy Ultrasonic Sensor
Powerful Control System
Powerful Control System
Compared with the previous generation of Raspberry Pi, RaspberryPi 4B makes breakthrough in processor speed, multimedia performance, memory and connection. The combination of RaspberryPi 4B and RaspberryPi expansion board significantly enhances MasterPi’s AI performance!
Compared with the previous generation of Raspberry Pi, RaspberryPi 4B makes breakthrough in processor speed, multimedia performance, memory and connection. The combination of RaspberryPi 4B and RaspberryPi expansion board significantly enhances MasterPi’s AI performance!
- Independent power switch for stable power supply
- 6-channel PWM servo ports with over-current protection
- Loaded MCU to offload the workload of Raspberry Pi and reduce resource usage
- Loaded with RGB light, buzzer, LED light, etc.
- Three IIC ports for expansion
- Lead out multiple GPIO pins for development
- 4PIN anti-reverse ports compatible with Hiwonder sensors
Raspberry Pi 4B VS Raspberry Pi CM4
Raspberry Pi 4B VS Raspberry Pi CM4
Product Parameter
Packing List
| Item | Specification |
| Product dimension | 185*162*347mm |
| Product weight | 1.1kg |
| Body material | metal bracket |
| Camera resolution | 480P |
| Robotic arm DOF | 4DOF+gripper |
| Battery | 18650 lithium battery |
| Battery life | work for 60min continuously |
| Hardware | Raspberry Pi 4B and Raspberry Pi expansion board |
| Software | PC software, iOS/Android APP |
| Communication | Wi-Fi and Ethernet |
| Servo | LD-1501MG digital servo & LFD-01M micro servo |
| Control Method | PC and phone control |
| Package Size | 330*290*85mm (length*width*height) |
| Package Weight | about 1.6kg |
| Packing List | 1* MasterPi robotic arm (assembled) 1* Chassis bracket set 1* Raspberry Pi 4B (4GB/ 8GB) with SD card(Optional) 1* Raspberry Pi expansion board 2* 18650 lithium battery 1* Battery case 1* Charger 1* Micro USB cable 4* Orange mecanum wheel 4* TT motor 1* 4PIN wire 1* Servo position adjuster 3* Block (3*3cm) 3* Heat sink 1* Cooling fan 1* Screwdriver 1* Screw bag 4* White wheel coupling |
QUESTIONS & ANSWERS
Ask a Question-
can I have the cad files for the MasterPi kit
Sorry, we cannot offer cad files for MaterPi, but we offer shematics, source code and system image for it:)
